Example of Python Generator Function.

One of the great features of Python is Generator Functions.  Generator functions allow you to convert any function to a generator function by simply including the yield keyword somewhere in the function body.  When a generator function is called, the response is a generator object, which can be iterated over among other things.

To boil this down to basics, generator functions allow you the programmer to create a function which yields one value at a time (and pauses until the next value is requested) until you decide it is done.  This opens endless possibilities for converting sequences, creating sequences, filtering, and more.

The following example is a generator function which will take a simple list or iterator and return pairs of (element, previous_element).  This is a great use for generators and the yield statement.

Generator Function:

def lineandlast(listish, first=True, last=True):
    iterator = iter(listish)
    lastline = next(iterator)

    if first:
      yield lastline, None

    for line in iterator:
        yield line, lastline
        lastline = line

    if last:
        yield None, lastline

Example:

for line, last in lineandlast([1,2,3,4,5]):
    print(line, last)

Output:

1 None
2 1
3 2
4 3
5 4
None 5

Notes:
There are two keyword arguments, first and last, which can be used to control the output of the first and last items on the output example above.

VisPy Sinewave Demo

VisPy is quite an interesting tool.  They say it is for “scientific visualization”.  Here is an example of that.  I took a demo from their github page and added a little code to generate a sinewave.  The cool thing is that the graph, scaling, panning, zooming, and redrawing all come out of the box.

I previously wrote about installing VisPy.  Thanks to the great efforts of some unnamed people, Python on Windows is really working nicely now.

Here is a screenshot:

vis

Here is the code:

Installing VisPy on Windows 10

VisPy is a Python library for interactive scientific visualization that is designed to be fast, scalable, and easy to use.

Here is how I installed it:

First I installed the latest Python 3.6 on Windows 10 by following the directions on http://www.python.org.  Once this was installed, I opened up Windows PowerShell and ran this command:

py -m pip upgrade vispy PyQt5 --user

I found some sample code here, and using NotePad++, copied and pasted it, saving it to Desktop\Code\v1.py

https://github.com/vispy/vispy/blob/master/examples/basics/gloo/animate_shape.py

In PowerShell, I changed to the directory that I saved the python code to and ran it:

cd Desktop\Code
py .\v1.py

Here is the output:

zzzz

It’s a pretty smooth and clean looking UI.  It seems extremely powerful, but I’ll need to dig in and see what makes it tick…

2D Sine Wave Example Using PyOpenGL

Here is an example of a moving 2D sine wave using Python 3, PyGame, and PyOpenGL.  See a https://blog.gahooa.com/2018/02/11/pygame-and-opengl-on-windows-10/  for how to install them.

sine

This sample program is designed to have a 100×60 unit working area with a 10 unit buffer around the edges.  You can see the axis in the lower-left (0,0) where Y+ is up, and X+ is to the right.

The structure of the program was created to make it super easy to work on the “guts” of the graphics without getting it confused with the “bookkeeping” end of OpenGL or PyGame.

Note: the glOrtho() command is how 2D “parallel perspective” is setup.  It defines the left, right, bottom, top, near plane, and far plane.  Because it is parallel, there is not the notion of a “camera” per-se, but rather section of the plane that should be viewed.  Documented here:

https://www.khronos.org/registry/OpenGL-Refpages/gl2.1/xhtml/glOrtho.xml

Here is the code!

PyGame and OpenGL on Windows 10

First I went to http://www.python.org and downloaded the latest version of Python for windows.  I made sure to select the option to add it to the system path.

Then I opened windows PowerShell (just a nicer term)

py -m pip install pygame --user
py -m pip install numpy --user
py -m pip install pyopengl --user

(I also installed NoteTab++, a nice text editor)

From there, I went to github and copied one of the examples from https://github.com/pygame/pygame/blob/master/examples/glcube.py and saved it on my desktop as myglcube.py.

In PowerShell, you just type:

cd Desktop
py -m myglcube

Here is my example:

zzz

(here is the code)





Playing with Turtle XYZ

3D Rendering has always interested me, but I’ve never taken the time to mess around with it much.

When I was a kid I used to do stuff like this in Basic.  But I didn’t know trig or other similar functions so I was left to basic math and the random functions.

Here is a little turtle program (python) that will make a wrinkled fabric type display.

2015-12-18 - B163539.png
